• Key Features:

  IBR Roof Sheet and Corrugated Sheet Roll Forming Machine,
  Double Layer Roll Forming Machine,

  1. The chart of process flow:
  Decoiling---active feeding---roll forming---measuring length---cutting to length---product to stand

  2. Manual inner tight decoiler
  --Inner diameter of coil: 450mm-700mm
  --Maximum width of coiling: 1200mm
  --Maximum weight of loading: 6000kg

  3. Main forming machine
  --Number of forming steps: Upper 18 stations, Down 18 stations
  --Material of shaft: No. 45 steel adjustable treatment. Diameter: 70mm
  --Material of roller: high grade No. 45 steel ( plated chrome on surface )
  --Main motor power: 5.5 KW
  --Forming speed: 8-13m/min
  --Stand: No. 280 steel welding
  --The plating chromium of roller surface: 0.05mm

  4. Hydraulic cutter
  --Material of blade: Cr12 mould steel with quenched treatment 60-62
  --Cutting system: Adopt advanced hydraulic drive, after forming automatic cut, no twist, no wasting, high safe factor. (Main motor stop cutting)
  --Hydraulic Power: 4 KW
  --Computer adopt PLC, Panasonic
  --Computer operating board: Touch screen
  --Length tolerance: +/-1.5mm
  --Hydraulic pressure: 12Mpa

  Contact Person: Jason Pang
  Mobile: 0086-15921994913

• Key Applications:

  Used for manufacturing the construction materials: roofing sheet, corrugated sheet, wall panel and so on

• Specifications:

  According to the drawing of the profile and customer's request

• The other roll forming machines we offer:

  1) C/U/Z Purlin Roll Forming Machine
  2) Roof/Glaze Tile Roll Forming Machine
  3) Double Layer Roll Forming Machine
  4) IBR Roofing Sheet Roll Forming Machine
  5) Highway Guardrail Roll Forming Machine
  6) ABM K Span Roll Forming Machine
  7) Downspout Roll Forming Machine and Elbow Machine
  8) Rain Gutter Roll Forming Machine
  9) Bemo Sheet Roll Forming Machine
  10) Embossing Machine for Steel Coil
  11) Slitting Machine and Cut-to-length machine
  12) Roof Ridge Cap Roll Forming Machine
  13) Steel Floor Deck Roll Forming Machine
  14) Cable Tray Roll Forming Machine
  15) Rack Beam System Roll Forming Machine
  16) EPS/PU Sandwich Panel Production Line and Roll Forming Machine
  17) Rolling Shutter Roll Forming Machine
  18) PU Foaming Garage Door Roll Forming Machine
  19) Light Steel Keel Roll Forming Machine
  20) Hydraulic Roof Curving Machine
